600W CMY CTO Profile BSW Framing Moving Head Light for Events QG-600BSW

loading

Share to:
twitter sharing button
facebook sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
kakao sharing button
sharethis sharing button
600W white LED
Color Temperature:6800K
CRI: 90 Optional
0~100% linear dimming
4.5°~ 50° linear zoom
LCD Display
Availability:
  • QG-600BSW

  • AVQ

Product Parameters

ParameterValue
Light Source600W white LED
LED Lifetime20000 hours
CRI75/ 90
Color Temperature6800K
Zoom4.5°~ 50° linear zoom
Power900W
Input Voltage100-240V 50/60 Hz
Framing4 Individually positionable Shutter Blades
Gobo WheelStatic: 7 gobos; Rotating: 7 gobos
Animation WheelDynamic effects (flame, water, etc.)
Color6 colors + open
CTOLinear adjustment
CMYLinear color mixing
PrismRotating 3-faced prism
FocusAutomatic
Iris5%-100%
Strobe0-20Hz
Frost system0~100%
DisplayLCD
Control ModesDMX512, RDM, Auto, Master/Slave, Sound
Channels36CH
Housing MaterialDie-casting Aluminum
Net Weight35KG
Gross weight45KG
Product size424286770(mm)
Carton size730690590 (mm)



600w Framing Beam Spot Wash Moving Head Light

Product Description:

600W CMY CTO Profile BSW Framing Moving Head Light

A versatile and high-performance LED moving head light designed for professional lighting applications.

This powerful moving head light combines a wide range of features, including CMY color mixing, CTO correction, and precise framing, making it ideal for creating dynamic and customized lighting effects.

Key Features of 600W CMY CTO Profile BSW Framing Moving Head Light

Core Features

  • Precise Beam Shaping: Four independently controlled framing shutters allow for highly customizable beam shapes.

  • Versatile Color Mixing: CMY and CTO color mixing offer a wide color gamut and accurate color temperature adjustment.

  • Dynamic Effects: Gobo wheels, animation wheel, and prism effects create diverse visual patterns.

  • Smooth Dimming: 0-100% linear dimming for precise control of light output.

Optical System

  • Adjustable Zoom: Linear zoom from 4.5° to 50° allows for various beam sizes.

  • Automatic Focus: Ensures a sharp and clear image.

  • Iris Control: Precisely adjusts the beam size for different applications.

Control and Operation

  • Multiple Control Modes: DMX512, RDM, and Auto modes offer flexibility for various lighting setups.

  • User-Friendly Interface: LCD display for easy setup and operation.

  • Sound Activation: Syncs the light with music for dynamic performances.

Construction and Durability

  • Robust Design: Die-cast aluminum housing ensures durability and heat dissipation.

  • Weather Resistant: Suitable for indoor and outdoor use.

Additional Features

  • Strobe Effects: Creates dynamic visual effects with adjustable speed.

  • Frost System: Softens the light output for a wash effect.

These features make the 600W CMY CTO Profile BSW Framing Moving Head Light a versatile and powerful lighting tool for a wide range of applications, including stage lighting, architectural lighting, and events.

FAQ for 600W CMY CTO Profile BSW Framing Moving Head Light

General Applications

  • What are the primary applications of the 600W CMY CTO Profile BSW Framing Moving Head Light?

    • This light is designed for both indoor and outdoor use, making it suitable for a wide range of applications, including stage lighting, architectural lighting, and event lighting.

Specific Use Cases

  • Can this light be used for large-scale events?

    • Yes, its powerful output and precise beam control make it ideal for large concerts, festivals, and corporate events.

  • Is this light suitable for parties and weddings?

    • Yes, it can create dynamic and eye-catching effects for weddings and other celebratory events.

  • Can this light be used in hotels and hospitality venues?

    • Yes, it can be used to enhance the ambiance of hotels, restaurants, and lounges.

  • Is this light suitable for auditoriums and conference halls?

    • Yes, it can be used to create professional-looking lighting setups for presentations and conferences.

Technical Specifications

  • What is the power consumption of this light?

    • The power consumption is 900W.

  • What is the color temperature of the light source?

    • The color temperature is 6800K.

  • What is the CRI of this light?

    • The CRI (Color Rendering Index) is 75/ 90, ensuring accurate color reproduction.

Features and Benefits

  • What are the key features of this light?

    • Key features include CMY color mixing, CTO correction, gobo effects, framing shutters, and a wide zoom range.

  • Can the color temperature be adjusted?

    • Yes, the CTO (Color Temperature Orange) correction allows for adjustment of the color temperature.
