800W LED Spot Cutting Moving Head Light with Cmy and CTO QG-800BSW

loading

Share to:
twitter sharing button
facebook sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
kakao sharing button
sharethis sharing button
750W white LED
Color Temperature:6500K
CRI: 90/75
0~100% linear dimming
6°~ 50° linear zoom
LCD Display
Availability:
  • CTO QG-800BSW

  • AVQ


Product Parameters

ParameterValue
Light Source750W white LED
LED Lifetime20000 hours
CRI90/75
Color Temperature6500K
Zoom6°~ 50° linear zoom
Power800W
Input Voltage100-240V 50/60 Hz
Lumen28000lm
Framing4 groups, 8 directions
Gobo WheelStatic: 11 gobos; Rotating: 7 gobos
Animation WheelDynamic effects (flame, water, etc.)
Color6 colors + open
CTOLinear adjustment
CMYLinear color mixing
Prism3 facet, 6 facet
FocusAutomatic
Iris6%-100%
Strobe0-20Hz
Frost35°-65°
DisplayLCD
Control ModesDMX 512, RDM, ArtNet, Auto, Master/Slave, Sound
Channels36/42/60
Housing MaterialDie-casting Aluminum
Net Weight38KG
Gross weight42KG
Packing size90.5x56x45.5CM

Light Source

Light Source:750W white LED

LED lifetime: 20000 hours

CRI: 90/75

Color Temperature:6500K

Zoom: 6°~ 50° linear zoom


Power supply

Power:800W

Input Voltage:100-240V 50/60 Hz

Lumen:28000lm


Optical System

Framing:4 groups and eight directions of blade, multiple design

static gobo wheel: 11 gobos + open one

rotating gobo wheel:7 gobos + open, interchangeable, indexable

Animation wheel: dynamic effect like flame or water, etc.

Color:one color wheel, 6 colors+ Open

CTO:Independent CTO, color temperature can be linear adjusted

CMY:Independent CMY, with linear color change, limitless color mixing

Prism:3 facet linear prism,6 facet linear prism

Focus:Automatic focus

Iris: 6%-100% motorized linear iris adjustment

Strobe:0-20Hz, 1-25 times/second

Frost:35°-65° With frost effect, with 3 frost lever-heavy, medium and light


Control

Display:LCD display

Control Mode: DMX 512, RDM, Artnet (Optional), Auto-running, Master/salve, Sound active, Built-in program

Channel:36/42/60CH


Connections

Data In/Out: 3pin or 5-pin XLR, True One connector


Construction

Housing Material: Die-casting Aluminum

Housing Color: Black


Package

Net Weight:38KG

Gross weight: 42KG

Packing size:90.5x56x45.5CM




Product Description:

800W LED Spot Cutting Moving Head Light with CMY and CTO


A versatile and high-performance LED moving head light designed for professional lighting applications.

This powerful moving head light combines a wide range of features, including CMY color mixing, CTO correction, and precise framing, making it ideal for creating dynamic and customized lighting effects.


Key Features of 800W LED Spot Cutting Moving Head Light with CMY and CTO

Core Features

  • Powerful Illumination: 750W LED provides high brightness and a long lifespan of 20,000 hours.

  • Precise Color Control: CMY and CTO color mixing offer a wide color gamut and accurate color temperature adjustment.

  • Versatile Beam Shaping: 4-way framing shutters enable precise control of the light beam.

  • Dynamic Effects: Gobo wheels, animation wheel, and prism effects create diverse visual patterns.

Optical System

  • Adjustable Zoom: Linear zoom from 6° to 50° allows for various beam sizes.

  • Automatic Focus: Ensures a sharp and clear image.

  • Iris Control: Precisely adjusts the beam size for different applications.

Control and Operation

  • Multiple Control Modes: DMX512, RDM, and ArtNet compatibility for flexible integration into lighting systems.

  • User-Friendly Interface: LCD display for easy setup and operation.

  • Sound Activation: Syncs the light with music for dynamic performances.

Construction and Durability

  • Robust Design: Die-cast aluminum housing ensures durability and heat dissipation.

  • Weather Resistant: Suitable for indoor and outdoor use.

Additional Features

  • Strobe Effects: Creates dynamic visual effects with adjustable speed.

  • Frost Filter: Softens the light output for a wash effect.

These features make the 800W LED Spot Cutting Moving Head Light a versatile and powerful lighting tool for a wide range of applications, including stage lighting, architectural lighting, and events.

English Application Scenarios for 800W LED Spot Cutting Moving Head Light with CMY and CTO

Expanded and Detailed Applications

Here are some more specific examples of how this product can be used in various settings:

  • Theatrical Productions:

    • Create dynamic lighting effects for stage productions, musicals, and operas.

    • Illuminate sets and props with precise color and beam control.

  • Concerts and Live Events:

    • Provide eye-catching visuals for concerts, festivals, and other live performances.

    • Highlight performers and create immersive atmospheres.

  • Corporate Events:

    • Enhance presentations, product launches, and conferences with custom lighting designs.

    • Create branded environments and engage audiences.

  • Nightclubs and Bars:

    • Create energetic and visually stimulating atmospheres for nightclubs and bars.

    • Provide dynamic lighting effects for dance floors and stages.

  • Weddings and Special Events:

    • Customize lighting to match the theme and atmosphere of weddings and other special events.

    • Create romantic and elegant lighting designs.

  • Houses of Worship:

    • Enhance religious services with dynamic lighting effects.

    • Create a sense of awe and inspiration.

General Applications (List Format)

  • Entertainment Venues: Theaters, concert halls, nightclubs, and bars.

  • Corporate Events: Conferences, product launches, and trade shows.

  • Weddings and Special Events: Weddings, parties, and galas.

  • Houses of Worship: Churches, synagogues, and mosques.

  • Broadcast and Film: Television studios and film sets.

Key Benefits in These Applications

  • Versatility: Suitable for a wide range of applications due to its customizable features.

  • Impactful Visuals: Creates stunning visual effects to enhance any event.

  • Professional Quality: Delivers high-quality performance and reliability.

  • Precise Control: Offers precise control over color, beam shape, and movement.

This 800W LED Spot Cutting Moving Head Light is an excellent choice for lighting professionals seeking a versatile and powerful lighting fixture.


FAQ for 800W LED Spot Cutting Moving Head Light with CMY and CTO

General Applications

  • What are the primary applications of the 800W LED Spot Cutting Moving Head Light?

    • This light is designed for both indoor and outdoor use, making it suitable for a wide range of applications, including stage lighting, architectural lighting, and event lighting.

Specific Use Cases

  • Can this light be used for large-scale theatrical productions?

    • Yes, its powerful output and precise beam control make it ideal for large theaters.

  • Is this light suitable for large parties and events?

    • Yes, it can create dynamic and eye-catching effects for parties and events.

  • Can this light be used for concerts and live performances?

    • Yes, it's perfect for creating dramatic lighting effects in live performances.

  • Is this light suitable for wedding ceremonies?

    • Yes, it can add elegance and sophistication to wedding ceremonies.

Technical Specifications

  • What is the power consumption of this light?

    • The power consumption is 800W.

  • What is the color temperature of the light source?

    • The color temperature is 6500K.

  • What is the CRI of this light?

    • The CRI (Color Rendering Index) is 90/75, ensuring accurate color reproduction.

Features and Benefits

  • What are the key features of this light?

    • Key features include CMY color mixing, CTO correction, gobo effects, framing shutters, and a wide zoom range.

  • Can the color temperature be adjusted?

    • Yes, the CTO (Color Temperature Orange) correction allows for adjustment of the color temperature.
