Pix-3X Retro stage light
AVQLIGHT
| Power supply | 100-240V - 50/60Hz |
|---|---|
| Power consumption | 200W |
| LED source | 3 x 60W 1800K, 6 x 5W RGB |
| Luminous flux | >7500lm |
| Field angle | 100° |
| Optic | High efficiency optic system |
| Effect | Power led, Sim-tungsten |
| Dimmer mode | 8 &16 Bit |
| DMX mode | 18 / 21 / 33CH |
| Control mode | DMX, Auto, Master-slave |
| Protocol | DMX, RDM |
| Mask Face | 3 Choose 1 |
| IP rating | 40 |
| Working Condition | -30° ~ 70°C |
| Power & DMX link | - Powercon 3 x 1.0 in & out - DMX: 3/5 pin DMX in & out |
| Box Info | - Carton: 2 in 1 - Case: 4 in 1/8 in 1 |
| Size(mm) | - Light: 910 x 120 x 77 - Carton: 1230 x 255 x 185 - Case: 990 x 640 x 480 |
| Weight(kg) | - Net Weight: 5.2 - Box Weight: 11 - Case Weight: 70 (8in1) |
| Optional Accessories | - Floor stand part 2 - Stand plate - Flying case - Clamp |
