mini-380W-2
AVQLIGHT
1. Wide voltage: AC90V-235V 50-60Hz
2. Wide voltage driving power supply: 600W
3. Imported light source system: 371W (Osram) (light source brand can be configured according to customer requirements)
4. Color temperature; 8000K
5. Color system: Color disk: 14+white light, rainbow effect
6. Colorful effect disk
7. Pattern system: Pattern disk: 17 fixed patterns + white light
8. Eight-color aperture effect
9. Focusing system: Electronic focusing
10. Atomization: With atomization function, soft light effect can be achieved
11. Strobe; dual motor independent strobe effect, 0.5-20 times/second, adjustable speed
12. Motor: XY axis uses three-phase motor, which makes the speed of the lamp high and the positioning angle accurate!
13. Dimming curve: 0%-100% linear dimming, smooth and flicker-free
14. Beam angle: 2-5°
15. Dual channels: 24 channels or 28 channels
16. Lens diameter: 160mm
17. Waterproof grade: IP55
18. Control mode: DMX 512, self-propelled, master-slave self-propelled, RDM function, can use large controller to control remote address code.
19. Prism system: 8 prisms and (8+16) prisms (prisms can be configured according to customer requirements).
20. Display screen: LCD display screen, adapt to different installation positions, can rotate 180°
21. Horizontal and vertical: use high-precision three-phase motor, accurate positioning, smooth operation, automatic positioning correction
22. Horizontal: 540° rotation, resolution 8/16Bit, with fine adjustment
23. Vertical: 270° rotation, resolution 8/16Bit, with fine adjustment
24. Cooling system: physical fan heat method is adopted, and the heat flow of the lamp is analyzed and calculated by software with air convection system method, which can quickly solve the internal heat of the body, prolong the light decay time of the light source, ensure the service life of the bulb, and design a low-noise cooling system with excellent fan drive performance and extremely low noise.
25. Installation method: upright/inverted
26. Lamp body size: 36*31*60cm Net weight: 20KG, gross weight 24KG
Masterpiece of craftsmanship: high-end appearance, huge energy, thick light column The waterproof beam lamp has reached high standards in terms of optics, structure, appearance and other aspects. It adopts the most advanced technology, high-brightness light source, optical technology and rigorous industrial design to ensure the perfect presentation of lighting design.
