BEAM-550 waterproof Moving Head Beam IP65 with CMY
AVQ
·Power Supply:AC 100-240V,50/60Hz
·Power consumption:900W
·Light Source:OSRAM SIRIUS HRI 550W
·Lamp life expectancy: 1500 Hours
·Color Temperature:7500K
·Diameter of lens:265mm
·Color Wheel:linear CMY color mixing,1 color wheel:14 color+white light,
Semi- color and rainbow effect(adjustable rotating speed and direction)
·Gobo Wheel:1 static gobo wheel:19 gobos+open;
gobo shake(adjustable rotating speed and direction)
·Prism:8-facet prism,16-facet prism,rotatable in both directions and overlayable
·Zoom: electronic linear zoom 0°-1.8°
·Focus:Variable motorized focus(0-100%)
·Frost:An independent frost effect
·Dimmer: 0-100% linear electronic dimmer
·Strobe: 1-25Hz/s,adjustable speed
·Movement:Pan: 540°,8/16 Bit movement resolution
Tilt: 270°,8/16 Bit movement resolution
Automatically accurate positioning
·Control mode:DMX512,RDM,Sound,Master/Slave,Auto
·DMX Channel:20/28 CH
·Protection Rating: IP66
·Product Size:546*301*902mm,N.W.:59.5kg
·Carton size:720*470*1135mm,G.W:68.8
·Power Supply:AC 100-240V,50/60Hz
·Power consumption:900W
·Light Source:OSRAM SIRIUS HRI 550W
·Lamp life expectancy: 1500 Hours
·Color Temperature:7500K
·Diameter of lens:265mm
·Color Wheel:linear CMY color mixing,1 color wheel:14 color+white light,
Semi- color and rainbow effect(adjustable rotating speed and direction)
·Gobo Wheel:1 static gobo wheel:19 gobos+open;
gobo shake(adjustable rotating speed and direction)
·Prism:8-facet prism,16-facet prism,rotatable in both directions and overlayable
·Zoom: electronic linear zoom 0°-1.8°
·Focus:Variable motorized focus(0-100%)
·Frost:An independent frost effect
·Dimmer: 0-100% linear electronic dimmer
·Strobe: 1-25Hz/s,adjustable speed
·Movement:Pan: 540°,8/16 Bit movement resolution
Tilt: 270°,8/16 Bit movement resolution
Automatically accurate positioning
·Control mode:DMX512,RDM,Sound,Master/Slave,Auto
·DMX Channel:20/28 CH
·Protection Rating: IP66
·Product Size:546*301*902mm,N.W.:59.5kg
·Carton size:720*470*1135mm,G.W:68.8
The AVQLIGHT 550 is a powerful moving head beam light. It features IP65 protection. This makes it suitable for outdoor use. The light source is an OSRAM SIRIUS HRI 550W lamp. It offers a bright, focused beam.
This moving head has CMY color mixing. It also includes a color wheel with 14 colors plus white. The fixture provides semi-color and rainbow effects. Users can adjust rotation speed and direction.
The gobo wheel has 19 static gobos plus open. It offers gobo shake with adjustable speed and direction. It includes two prisms: an 8-facet and a 16-facet. These prisms rotate in both directions and can overlay.
The fixture features electronic linear zoom from 0° to 1.8°. It also has variable motorized focus. The focus range is 0-100%. An independent frost effect is included.
Dimming is linear from 0-100%. The strobe effect is adjustable from 1-25Hz/s. Pan movement is 540° with 8/16 bit resolution. Tilt movement is 270° with 8/16 bit resolution. It has automatic accurate positioning.
Control modes include DMX512, RDM, Sound, Master/Slave, and Auto. It offers 20 or 28 DMX channels.
Parameter | Value |
Power Supply | AC 100-240V, 50/60Hz |
Power Consumption | 900W |
Light Source | OSRAM SIRIUS HRI 550W |
Lamp Life Expectancy | 1500 Hours |
Color Temperature | 7500K |
Lens Diameter | 265mm |
Color Wheel | Linear CMY mixing, 14 colors + white, Semi-color, Rainbow effect |
Gobo Wheel | 19 static gobos + open, gobo shake |
Prism | 8-facet, 16-facet, bi-directional rotation, overlayable |
Zoom | Electronic linear 0°-1.8° |
Focus | Variable motorized (0-100%) |
Frost | Independent effect |
Dimmer | 0-100% linear electronic |
Strobe | 1-25Hz/s, adjustable speed |
Pan | 540°, 8/16 Bit resolution |
Tilt | 270°, 8/16 Bit resolution |
Positioning | Automatic accurate positioning |
Control Mode | DMX512, RDM, Sound, Master/Slave, Auto |
DMX Channel | 20/28 CH |
Protection Rating | IP66 |
Product Size | 546301902mm |
Net Weight | 59.5kg |
Carton Size | 7204701135mm |
Gross Weight | 68.8kg |
Powerful Light Source: Equipped with an OSRAM SIRIUS HRI 550W lamp, delivering a high-output, bright beam. The lamp has a life expectancy of 1500 hours.
Precise Optics: Features a 265mm lens diameter for focused light projection. The color temperature is 7500K.
Versatile Color System: Offers linear CMY color mixing for a wide range of colors. A separate color wheel with 14 colors plus white provides additional color options. It also has semi-color and rainbow effects with adjustable speed and direction.
Dynamic Gobo Effects: Includes a static gobo wheel with 19 gobos plus an open position. Gobo shake with adjustable speed and direction adds dynamic texture to projections.
Multiple Prism Effects: Features two prisms: an 8-facet and a 16-facet prism. Both prisms can rotate in both directions and be overlaid for complex visual effects.
Flexible Zoom and Focus: Provides electronic linear zoom from 0° to 1.8° for beam angle adjustment. Variable motorized focus (0-100%) ensures sharp image projection at various distances.
Independent Frost Effect: An independent frost effect softens the light output, creating a wash effect when needed.
Smooth Dimming and Strobe: Offers 0-100% linear electronic dimming for smooth intensity control. The strobe effect is adjustable from 1-25Hz/s.
Precise Movement Control: Offers pan movement of 540° and tilt movement of 270°. Both pan and tilt have 8/16 bit movement resolution for precise positioning. It has automatically accurate positioning which ensures accurate movement and return to position.
Multiple Control Options: Supports DMX512, RDM, Sound, Master/Slave, and Auto control modes for flexible system integration. Offers 20 or 28 DMX channel modes.
Robust and Weatherproof Design: Features an IP66 protection rating, making it suitable for outdoor use in various weather conditions. This protects it from dust and water ingress.
Robust Construction: The product size is 546301902mm and its net weight is 59.5kg. The carton size is 7204701135mm and gross weight is 68.8kg. This indicates a robust construction that can withstand transportation and use.
Wide Voltage Compatibility: Compatible with AC 100-240V, 50/60Hz power supplies, making it suitable for use in various regions. The power consumption is 900W.
Outdoor Performances: The IP65 rating makes it suitable for outdoor events. It can withstand various weather conditions. This includes concerts, festivals, and outdoor theatrical productions.
Professional Stage Lighting: The powerful beam and versatile features make it ideal for professional stage lighting. This includes concerts, tours, and large-scale events. It can create dynamic lighting effects.
Entertainment Lighting: Suitable for various entertainment venues. This includes nightclubs, bars, and entertainment centers. It can create exciting and dynamic lighting atmospheres.
Theater and Television Lighting: Its precise movement and color mixing capabilities make it suitable for theater and television productions. It can provide accurate and controlled lighting.
Architectural and Landscape Lighting: The powerful beam and weatherproof design make it suitable for architectural and landscape lighting. This includes highlighting buildings, monuments, and landscapes. It can create dramatic lighting effects.
Large Venue Illumination: The long throw and powerful output of the 550W lamp make it suitable for large venues. This includes stadiums, arenas, and large event spaces. It can provide strong beam effects across long distances.
Rental and Touring Applications: The robust construction and weatherproof design make it suitable for rental and touring applications. It can withstand the rigors of transportation and frequent use.
Special Effects Lighting: The multiple prism effects, gobo options, and zoom capabilities make it suitable for creating special lighting effects. This includes mid-air beam effects and textured projections.
Q: What is the IP rating of this moving head?
A: The IP rating is IP65. This means it is protected against dust and water ingress from low-pressure jets.
Q: What are the control options?
A: It supports DMX512, RDM, Sound, Master/Slave, and Auto control modes.
Q: What are the pan and tilt ranges?
A: The pan range is 540° and the tilt range is 270°. Both have 8/16 bit resolution.
Q: Does it have zoom and focus functions?
A: Yes, it has electronic linear zoom (0°-1.8°) and variable motorized focus (0-100%).
Q: What are the color options?
A: It has linear CMY color mixing and a color wheel with 14 colors plus white. It also includes semi-color and rainbow effects.
Q: What prism effects are available?
A: It features an 8-facet prism and a 16-facet prism, both rotatable and overlayable.
Q: Is this fixture suitable for outdoor use?
A: Yes, the IP65 rating makes it suitable for outdoor use.
Q: What is the lamp life?
A: The lamp life expectancy is 1500 hours.
Q: What is the power consumption?
A: The power consumption is 900W.
The AVQLIGHT 550 is a powerful moving head beam light. It features IP65 protection. This makes it suitable for outdoor use. The light source is an OSRAM SIRIUS HRI 550W lamp. It offers a bright, focused beam.
This moving head has CMY color mixing. It also includes a color wheel with 14 colors plus white. The fixture provides semi-color and rainbow effects. Users can adjust rotation speed and direction.
The gobo wheel has 19 static gobos plus open. It offers gobo shake with adjustable speed and direction. It includes two prisms: an 8-facet and a 16-facet. These prisms rotate in both directions and can overlay.
The fixture features electronic linear zoom from 0° to 1.8°. It also has variable motorized focus. The focus range is 0-100%. An independent frost effect is included.
Dimming is linear from 0-100%. The strobe effect is adjustable from 1-25Hz/s. Pan movement is 540° with 8/16 bit resolution. Tilt movement is 270° with 8/16 bit resolution. It has automatic accurate positioning.
Control modes include DMX512, RDM, Sound, Master/Slave, and Auto. It offers 20 or 28 DMX channels.
Parameter | Value |
Power Supply | AC 100-240V, 50/60Hz |
Power Consumption | 900W |
Light Source | OSRAM SIRIUS HRI 550W |
Lamp Life Expectancy | 1500 Hours |
Color Temperature | 7500K |
Lens Diameter | 265mm |
Color Wheel | Linear CMY mixing, 14 colors + white, Semi-color, Rainbow effect |
Gobo Wheel | 19 static gobos + open, gobo shake |
Prism | 8-facet, 16-facet, bi-directional rotation, overlayable |
Zoom | Electronic linear 0°-1.8° |
Focus | Variable motorized (0-100%) |
Frost | Independent effect |
Dimmer | 0-100% linear electronic |
Strobe | 1-25Hz/s, adjustable speed |
Pan | 540°, 8/16 Bit resolution |
Tilt | 270°, 8/16 Bit resolution |
Positioning | Automatic accurate positioning |
Control Mode | DMX512, RDM, Sound, Master/Slave, Auto |
DMX Channel | 20/28 CH |
Protection Rating | IP66 |
Product Size | 546301902mm |
Net Weight | 59.5kg |
Carton Size | 7204701135mm |
Gross Weight | 68.8kg |
Powerful Light Source: Equipped with an OSRAM SIRIUS HRI 550W lamp, delivering a high-output, bright beam. The lamp has a life expectancy of 1500 hours.
Precise Optics: Features a 265mm lens diameter for focused light projection. The color temperature is 7500K.
Versatile Color System: Offers linear CMY color mixing for a wide range of colors. A separate color wheel with 14 colors plus white provides additional color options. It also has semi-color and rainbow effects with adjustable speed and direction.
Dynamic Gobo Effects: Includes a static gobo wheel with 19 gobos plus an open position. Gobo shake with adjustable speed and direction adds dynamic texture to projections.
Multiple Prism Effects: Features two prisms: an 8-facet and a 16-facet prism. Both prisms can rotate in both directions and be overlaid for complex visual effects.
Flexible Zoom and Focus: Provides electronic linear zoom from 0° to 1.8° for beam angle adjustment. Variable motorized focus (0-100%) ensures sharp image projection at various distances.
Independent Frost Effect: An independent frost effect softens the light output, creating a wash effect when needed.
Smooth Dimming and Strobe: Offers 0-100% linear electronic dimming for smooth intensity control. The strobe effect is adjustable from 1-25Hz/s.
Precise Movement Control: Offers pan movement of 540° and tilt movement of 270°. Both pan and tilt have 8/16 bit movement resolution for precise positioning. It has automatically accurate positioning which ensures accurate movement and return to position.
Multiple Control Options: Supports DMX512, RDM, Sound, Master/Slave, and Auto control modes for flexible system integration. Offers 20 or 28 DMX channel modes.
Robust and Weatherproof Design: Features an IP66 protection rating, making it suitable for outdoor use in various weather conditions. This protects it from dust and water ingress.
Robust Construction: The product size is 546301902mm and its net weight is 59.5kg. The carton size is 7204701135mm and gross weight is 68.8kg. This indicates a robust construction that can withstand transportation and use.
Wide Voltage Compatibility: Compatible with AC 100-240V, 50/60Hz power supplies, making it suitable for use in various regions. The power consumption is 900W.
Outdoor Performances: The IP65 rating makes it suitable for outdoor events. It can withstand various weather conditions. This includes concerts, festivals, and outdoor theatrical productions.
Professional Stage Lighting: The powerful beam and versatile features make it ideal for professional stage lighting. This includes concerts, tours, and large-scale events. It can create dynamic lighting effects.
Entertainment Lighting: Suitable for various entertainment venues. This includes nightclubs, bars, and entertainment centers. It can create exciting and dynamic lighting atmospheres.
Theater and Television Lighting: Its precise movement and color mixing capabilities make it suitable for theater and television productions. It can provide accurate and controlled lighting.
Architectural and Landscape Lighting: The powerful beam and weatherproof design make it suitable for architectural and landscape lighting. This includes highlighting buildings, monuments, and landscapes. It can create dramatic lighting effects.
Large Venue Illumination: The long throw and powerful output of the 550W lamp make it suitable for large venues. This includes stadiums, arenas, and large event spaces. It can provide strong beam effects across long distances.
Rental and Touring Applications: The robust construction and weatherproof design make it suitable for rental and touring applications. It can withstand the rigors of transportation and frequent use.
Special Effects Lighting: The multiple prism effects, gobo options, and zoom capabilities make it suitable for creating special lighting effects. This includes mid-air beam effects and textured projections.
Q: What is the IP rating of this moving head?
A: The IP rating is IP65. This means it is protected against dust and water ingress from low-pressure jets.
Q: What are the control options?
A: It supports DMX512, RDM, Sound, Master/Slave, and Auto control modes.
Q: What are the pan and tilt ranges?
A: The pan range is 540° and the tilt range is 270°. Both have 8/16 bit resolution.
Q: Does it have zoom and focus functions?
A: Yes, it has electronic linear zoom (0°-1.8°) and variable motorized focus (0-100%).
Q: What are the color options?
A: It has linear CMY color mixing and a color wheel with 14 colors plus white. It also includes semi-color and rainbow effects.
Q: What prism effects are available?
A: It features an 8-facet prism and a 16-facet prism, both rotatable and overlayable.
Q: Is this fixture suitable for outdoor use?
A: Yes, the IP65 rating makes it suitable for outdoor use.
Q: What is the lamp life?
A: The lamp life expectancy is 1500 hours.
Q: What is the power consumption?
A: The power consumption is 900W.
