Waterproof 380W Beam Moving Head Stage Light for Building Bridgemini-380

loading

Share to:
twitter sharing button
facebook sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
kakao sharing button
sharethis sharing button
Outdoor waterproof grade IP56
Beam throw angle: 1.8°
OSRAM customized 381S lamp
Light outlet lens diameter: 16.CM
DMX512 international signal control
Total lamp power: 480W
Availability:
  • Outdoor-MINI380

  • AVQ

Light Sources

Bulb : OSRAM 381S lamp

Lifespan:2000 hours

Color temperature : 8500K

Power Supply

Voltage:AC100-240V  50-60Hz

Power :480W

Optical System

Beam angle: 1.8°

Diameter of lens:165mm

Strobe: 0.5-13Hz/s, adjustable speed

Dimmer: 0-100% linear electronic dimmer

Optical system: high-precision glass lens

Color Wheel:14 color+open,bidirectional rotation rainbow effect

Gobo Wheel:17 static gobos+open,gobo with shaking function

Prism:8-facet prism,(8+16)-facet prism,rotatable in both directions and overlayable

Zoom: electronic linear zoom, distance from 3m to infinite

Focus:Variable motorized focus(0-100%)

Frost:An independent frost

Movement

Pan: 540°,8/16 Bit movement resolution

Tilt: 270°,8/16 Bit movement resolution

Automatically accurate positioning

Control

Control:DMX512,RDM,Sound,Master/Slave,Auto

Channels: 16channels


Working Environment

Working temperature: -20-50℃

IP rate: IP56

Package

Size: 355x320x562mm

Weight:19kg

Carton Size:460x450x580mm,G.W.:23kg

Flight case size:820x790x630mm(2in1),G.W.:55kg



minini-381


Feature Description


Light Source Equipped with an OSRAM 381S lamp, offering a long lifespan of 2000 hours and a bright, cool white light output of 8500K.

Power Supply Designed for global use with AC100-240V, 50-60Hz input, and consumes 480W of power.

Optical System Features a high-precision glass lens for a focused 1.8° beam angle and a 165mm lens diameter. Includes a variable motorized focus, electronic linear zoom, and an independent frost filter for versatile lighting effects.

Color & Gobo Offers a 14-color color wheel with bidirectional rotation and a 17-static gobo wheel with a shaking function for dynamic patterns. An 8-facet and (8+16)-facet prism is included, allowing for various beam effects.

Movement Delivers smooth and precise pan and tilt movements with a resolution of 8/16 bits. It can rotate 540° on the pan axis and 270° on the tilt axis.

Control Supports DMX512, RDM, sound activation, master/slave, and auto modes for flexible control options. Offers 16 DMX channels for customization.

Construction Built with an IP56 rating, ensuring protection against dust and water, making it suitable for outdoor use.

Strobe & Dimmer Features an adjustable strobe speed from 0.5 to 13Hz/s and a linear electronic dimmer for precise control of light output.


Quantified data: Added specific values for beam angle, lens diameter, color temperature, and strobe speed.

Functional descriptions: Explained the purpose of features like the frost filter, zoom, and gobo shaking function.

User benefits: Highlighted the advantages of features like the long lifespan, versatile control options, and weatherproof design.

Clear and concise language: Avoided technical jargon and used simple, everyday language.

Additional features you may want to consider highlighting:


Noise level: If the product is particularly quiet, mention its low noise operation.

Cooling system: Describe the cooling system used to maintain optimal performance.

Safety features: Highlight any safety features, such as overload protection or thermal shutdown.

Mounting options: Specify the available mounting options, such as yoke, omega bracket, or truss clamp.

By providing a detailed and informative description, you can help potential customers understand the capabilities and benefits of your product.

Application Scenarios


Outdoor Landscapes: Illuminating trees, water features, and sculptures; creating ambient lighting for pathways and walkways.

Outdoor Performances: Providing aerial effects and gobo projections; highlighting stage performers and props.

Bridges: Illuminating bridge cables, arches, and towers; creating dynamic lighting sequences synchronized with music or other stimuli.

Landmark Buildings: Projecting logos, images, or animations onto buildings; creating temporary light installations for special events.

Large-Scale Parties: Providing dance floor lighting, uplighting, and special effects for weddings, corporate events, and nightclubs.

Architectural Facades: Mapping buildings with video content; creating interactive light installations that respond to user input.

Theme Parks: Creating immersive lighting experiences for haunted houses, water rides, and other attractions.

Museums and Galleries: Highlighting specific exhibits or artworks with focused lighting; creating dynamic lighting sequences to enhance visitor experience.

Retail Environments: Creating eye-catching window displays; highlighting seasonal promotions and new product launches.

FAQ


Q: What is the primary purpose of the AVQ Waterproof 380W Beam Moving Head Stage Light?

A: This light is designed for illuminating large outdoor spaces, including buildings, bridges, and event venues.


Q: Where can I use this light?

A: It can be used in various applications such as architectural lighting, bridge illumination, landscape lighting, event lighting, and theme parks.


Q: Is this light suitable for outdoor use?

A: Yes, it is specifically designed for outdoor use with an IP rating that protects it from dust and water.


Q: What types of effects can I create with this light?

A: You can create a wide range of effects, including color changes, gobo projections, and beam shaping.


Q: How is this light controlled?

A: It can be controlled via DMX512, RDM, sound activation, or built-in programs.
